Networking Basics: How to Implement EIGRP for IPv6

Let's take a look at the steps to implement EIGRP for IPv6 on two Cisco routers, R5 and R1, which are connected via the 1/0 fast ethernet interfaces. Using autonomous system 100, this process will implement EIGRP into the topology.

It's important to note that we'll be working exclusively with an IPv6 environment, with no IPv4 at any point. The topology will also add a loopback on R1. The IPv6 address of that loopback will then be advertised into the topology to ensure EIGRP is working. When that loopback appears on the R5, its presence will verify implementation.

How to Enable Unicast Routing Protocols

In the R5 command interface, enter global configuration mode and turn on "Unicast Routing Capabilities" for IPv6.

RouterR5# conf t

RouterR5(conf)# ipv6 unicast-routing

Creating an IPv6 Circuit on R5

Before implementing routing protocols, it's important to establish basic connectivity.

RouterR5(conf)# int fa1/0

RouterR5(conf-if)# ipv6 address 2001:51:51::5/64

RouterR5(conf-if)# no shut

The actual implementation would utilize the EUI-64 style of host addressing. EUI (Extended Unique Identifier) enables hosts to assign themselves unique 64-Bit IP Version 6 interface identifiers (EUI-64).

This provides an advantage over IPv4 — it eliminates the need for manual configuration or DHCP, which is required for IPv4. However, our example assigns the host portion of the address here for simplicity.

How to Configure R1

Now that the R5 has been set, open the R1 interface and input:

RouterR1# show ip int br

RouterR1# show ipv6 int br

These two commands will indicate that nothing is existing to interfere with the new implementation.

In the R1 command interface, enter global configuration mode and turn on 'Unicast Routing Capabilities' for IPv6.

RouterR1# conf t

RouterR1(conf)# ipv6 unicast-routing

Next, configure the fast ethernet 1/0 interface with an IPv6 address:

RouterR1(conf)# int fa1/0

RouterR1(conf-if)# ipv6 address 2001:51:51::1/64

RouterR1(conf-if)# no shut

Ping Test

The ping test verifies that Step 1 has been completed accurately. To do so, enter:

RotuerR1# ping 2001:51:51:5

This will ping the neighbor, R5, and should return a 100% success rate. This ping test confirms reachability in a routing protocol situation.

Creating the Loopback

Remaining in configuration for R1, configure a Loopback Interface for IPv6:

RouterR1(conf)# int lo 1

RouterR1(conf-if)#  ipv6 address 2001:1:1::1/64

EIGRP for IPv6 Configuration

Recall that in IPv6, EIGRP is configured under interfaces, as there is no more network command as in IPv4. Configure EIGRP for IPv6 on Interface fa1/0 on Router1:

RouterR1# conf t

RouterR1(conf)# int fa1/0

RouterR1(conf-if)# ipv6 eigrp 100

Do the same for the Loopback Interface lo1:

RouterR1# conf t

RouterR1(conf)# int lo1

RouterR1(conf-if)# ipv6 eigrp 100

Verifying EIGRP and Disabling Shutdown

In the current setup, there will be no routing protocols running after this inquiry. The interfaces have been enabled, but are not active.

To solve this, we need to bring up EIGRP for IPv6 on Router1:

RouterR1# conf t

RouterR1(conf)# ipv6 router eigrp 100

RouterR1(conf-rtr)# no shutdown

By default, the shutdown is enabled. This is a vital step to avoid implementation failure.

Assigning a Router ID

To complete the configuration on Router, we need to assign a route ID.

RouterR1(conf-rtr)# eigrp-router-id 1.1.1.1

Finally, to check that all our changes were successful:

RouterR1# show ipv6 protocols

Replicating in R5

Now, we need to replicate the EIGRP setup on Router5:

RouterR5# conf t

RouterR5(conf)# int fa1/0

RouterR5(conf-if)# ipv6 eigrp 100

RouterR5(conf-if)# ipv6 router eigrp 100

RouterR5(conf)# int lo 1

RouterR5(conf-if)#  ipv6 address 2001:1:1::5/64

RouterR5(conf-if)# ipv6 eigrp 100

RouterR5(conf-rtr)# no shutdown

RouterR5(conf-rtr)# eigrp-router-id 5.5.5.5

RotuerR5(conf-rtr)# no shut

To test with connectivity to Router1:

RouterR5# ping 2001:1:1::1

And finally, to check that process worked, in the both the R1 and R5 console, input:

RouterR1# show ipv6 protocols

RouterR5# show ipv6 protocols

This will confirm that EIGRP is actually running.
